Product Features
· Compact design, light weight
· Freeze instant waveform for real time S-T segment
· 3 Level audio / visual alarming
· Efficient resistance for interference od defibrillator and HF knife
· 12 inch screen, can be upgraded into touch screen
Technical Parameters
Display | 12 inch color screen | ECG | 5 Leads: RA, RL, V, LA, LL |
Application | cat, dog, horse, etc. | SPO2 | 0-100% |
Dimension and Weight | PR | 20-300 bpm | |
Monitor | 340 *245 *134 mm / 3KG | RESP | 0-150 bpm |
Package | 380 *340 *300 mm / 5 KG | Apnea Alarm:10-40s | |
Data Storage | Temp | T1, T2 | |
Trend Diagram | 720 h | Range:0-50℃ | |
NIBP Review | 1000 events | NIBP | method: pulse wave oscillometry |
Wave Review | 12 h | working mode: auto, manual, STAT | |
Alarm Review | 200 alarm events | ||
Standard accessories | NIBP cuff & tube, ECG Cable & electrodes, SPO2 sensor, TEMP probe, power cable | ||
Optional accessories | EtCO2 module | ||
